ProLights ECLIPSEHDTWC User Manual page 41

12 CANALI
MODE
FUNCTION
12 Ch
DIMMER SPEED MODE
Preset dimmer speed from display menu
Dimmer Speed Mode off
12
Dimmer speed Mode1 (fast speed)
Dimmer Speed Mode2 (middle speed)
Dimmer Speed Mode3 (slow speed)
13 CANALI
MODE
FUNCTION
13 Ch
RED
1
0~100%
RED FINE
2
0~100%
ORANGE
3
0~100%
ORANGE FINE
4
0~100%
GREEN
5
0~100%
GREEN FINE
6
0~100%
ROYAL BLUE
7
0~100%
ROYAL BLUE FINE
8
0~100%
BLUE
9
0~100%
BLUE FINE
10
0~100%
LIME
11
0~100%
LIME FINE
12
0~100%
DIMMER SPEED MODE
Preset dimmer speed from display menu
Dimmer Speed Mode off
13
Dimmer speed Mode1 (fast speed)
Dimmer Speed Mode2 (middle speed)
Dimmer Speed Mode3 (slow speed)
ECLIPSEHDTWC
16 CANALI
MODE
DMX
Value
16 Ch
1
000 - 051
052 - 101
102 - 152
2
153 - 203
204 - 255
3
4
DMX
Value
5
6
000 - 255
7
000 - 255
8
000 - 255
9
000 - 255
000 - 255 10
11
000 - 255
12
000 - 255
13
000 - 255
14
000 - 255
000 - 255
15
000 - 255
000 - 255
16
000 - 051
052 - 101
102 - 152
153 - 203
204 - 255
FUNCTION
DIMMER
0~100%
DIMMER FINE
0~100%
RED
0~100%
RED FINE
0~100%
ORANGE
0~100%
ORANGE FINE
0~100%
GREEN
0~100%
GREEN FINE
0~100%
ROYAL BLUE
0~100%
ROYAL BLUE FINE
0~100%
BLUE
0~100%
BLUE FINE
0~100%
LIME
0~100%
LIME FINE
0~100%
STROBE
No Function
Strobe Slow to Fast
DIMMER SPEED MODE
Preset dimmer speed from display menu
Dimmer Speed Mode off
Dimmer speed Mode1 (fast speed)
Dimmer Speed Mode2 (middle speed)
Dimmer Speed Mode3 (slow speed)
17
DMX
Value
000 - 255
000 - 255
000 - 255
000 - 255
000 - 255
000 - 255
000 - 255
000 - 255
000 - 255
000 - 255
000 - 255
000 - 255
000 - 255
000 - 255
000 - 010
011 - 255
000 - 051
052 - 101
102 - 152
153 - 203
204 - 255
