Table 45
NTMW44 Terminal Number Assignments
Card
Slot
1 & 2
3 & 4
5 & 6
7
8
9
11 & 12
13 & 14
15 & 16
17
18
19
Note: Main and expansion cabinets are NTMW08 cabinets.

Power requirements

Power requirements for the NTMW44 are shown in Table 46.
Table 46
Power requirements
Voltage
± 15.0 V DC
Chapter 12 — NTMW44 Universal Trunk Card
Card
First TN......Last TN
Assignment
1
3
5
7
8
9
11
13
15
17
18
19
Tolerance
± 5%
Meridian 1 Option 11C Compact
Type of
01 00......01 03
03 00......03 03
05 00......05 03
07 00......07 03
08 00......08 03
09 00......09 03
11 00......11 03
13 00......13 03
15 00......15 03
17 00......17 03
18 00......18 03
19 00......19 03
Idle current
306 ma
Technical Reference Guide
Page 119 of 136
