Page 134 of 136
Switch and LED
553-3121-100
Standard 2.0
Chapter 14 — NTMW50 RS232 Service Module Assembly
The NTMW50 has a BYPASS switch mounted on it, along with an LED
status indicator. The BYPASS switch provides a backup link between the
PMS and the Option 11C Compact, to be used if the Compact Mail card fails
or is powered down for any reason. The BYPASS switch allows the PMS to
continue to function during a failure. The green LED indicator is on when the
RSM is operating normally, and is off when the BYPASS switch is turned on.
September 1998
