Page 50 of 136 Chapter 6 — SDI ports

NTMW10 Fiber Receiver card

Parameter settings

553-3121-100 Standard 2.0
The baud rates available on all three ports are 300, 600, 1200, 2400, 4800,
9600 and 19200 baud. Table 24 shows the default settings.
Table 24
Default port configuration
TTY
Card
Number
0 0
1 0
2 0
The NTMW01 Fiber Receiver card located in the expansion cabinet supports
one Serial Data Interface (SDI) port.
Baud rates are selected by setting switches located in the faceplate the Fiber
Receiver card. The available settings are:
• 150, 300, 600, 1200, 2400, 4800, 9600 and 19200 baud
Other RS232 parameters are fixed as shown in Table 25.
Table 25
Fixed parameter settings
Parameter
Parity
Mode
Stop Bits
Data Bits
The port can be used for MTC/SCH/BUG modes.
September 1998
Port Use
0 MTC/SCH/BUG
1 MTC/SCH/BUG
2 CTY
Setting
None
Asynchronous
1
8
Configuration
1200/8/1/NONE
1200/8/1/NONE
1200/8/1/NONE
