NTN469GF
Nortel Networks
OPTera Metro 3500
Multiservice Platform
System Testing
Standard Release 12.0 Issue 1 November 2003
What's inside...
Safety instructions
System testing
323-1059-222

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OPTera Metro 3500 and is the answer not in the manual?

Questions and answers

pfigueroa
April 29, 2025

How do i obtain conection locally with my laptop

0
1 comments:
Mr. Anderson
May 15, 2025

To connect your laptop locally to the Nortel Metro 3500, follow these steps:

1. Power up the Nortel Metro 3500 system and wait at least 5 minutes for it to stabilize.
2. Use a local connection to access the system. This may involve connecting your laptop to the appropriate port on the network element using a serial or Ethernet cable, depending on the interface supported.
3. Log in to the network element using the Site Manager application. The login uses a challenge-response system that requires administrative access and a shared secret.
4. Once logged in, you can retrieve alarms and events, and perform provisioning tasks.

Exact cable types and port details are not provided.

This answer is automatically generated

0

Related Manuals for Nortel OPTera Metro 3500

Summary of Contents for Nortel OPTera Metro 3500

  • Page 1 NTN469GF 323-1059-222 Nortel Networks OPTera Metro 3500 Multiservice Platform System Testing Standard Release 12.0 Issue 1 November 2003 What’s inside... Safety instructions System testing...
