Chapter 8 — M2250 Attendant Console
Introduction
Description
Features
The M2250 Attendant Console is to assist in placing and extending calls in
and out of the Meridian 1 Option 11C Compact system. It is operated by an
attendant as the human interface between the system and the users.
This chapter describes the M2250 attendant console. The M2250 is driven
and powered by a digital line card.
The M2250 has the following features:
•
A four-line, 40 character, liquid crystal display (LCD) with backlighting
and adjustable viewing angle. Power, including backlighting, is
maintained during building power failures through the system battery
backup, if equipped.
•
In shift mode, the M2250 can have up to 20 TGB keys.
•
Up to 10 extra flexible feature keys (total of 20) in shift mode
•
An optional supporting stand that can be adjusted to nine different
positions.
•
A handset and headset volume adjustment slider control, situated below
the dial pad.
•
A physical connection to a serial data port through a subminiature D-type
female connector on the console back wall. This permits connection of
the console to the serial port of a personal computer.
Meridian 1 Option 11C Compact
Page 79 of 136
Technical Reference Guide
