Insertion loss limits

Table 4
Insertion loss limits
Connection
Line — Line
Line — Analog Trunk
Line — Digital Trunk
Analog Trunk — Analog Trunk
Analog Trunk — Digital Trunk
Digital Trunk — Digital Trunk
Chapter 2 — Transmission parameters
Notes to Table 3
Note 1: A satellite tie trunk connects a satellite or tributary PBX to a
main PBX. A tributary PBX does not have its own directory number for
incoming calls.
Note 2: The toll office designation is for a trunk to an office in the
public switched network with a higher rank than the local office (class 5).
Note 3: The 1.5Mb PRI and DTI have digital pads which are controlled
by Option 11C Compact software to provide the insertion loss given in
Table 3.
Table 4 gives the analog insertion loss limits for trunk and line connections.
Meridian 1 Option 11C Compact
Insertion Loss Variation Limits (dB)
+1.0
+ 0.7
+0.7
+0.7
+0.7
+0.2
Page 17 of 136
