Page 20 of 136 Chapter 2 — Transmission parameters

Return Loss

Table 7
Return Loss
Interface
2 Wire Line
2 Wire Trunk
553-3121-100 Standard 2.0
The return loss measures how closely the input impedance matches the
required impedance (source impedance). Return loss at an impedance
discontinuity in a transmission path is the ratio (in dB) of the power level of
an incident signal to the power level of the resulting reflected signal.
Echo Return Loss (ERL) is a weighted average of the return loss value over
the frequency range of 500 to 2500 Hz.
Single Frequency Return Loss (SFRL) is the lowest value of return loss in the
frequency range of 200 to 3200 Hz.
The return loss is measured against its characteristic input impedance (see
Table 7).
Reference Source is 0 dBmO.
Echo Return Loss (dB)
September 1998
>18
>22
Single Frequency
Return Loss (dB)
>12
>17
