Page 54 of 136 Chapter 7 — Meridian Modular Telephones

General description

553-3121-100 Standard 2.0
This chapter describes the various features and capabilities of the following
Meridian Modular Telephones.
M2006—a single line telephone with 6 programmable function keys.
See Figure 5 on page
M2008—a multi-line telephone with 8 programmable function keys. See
Figure 6 on page 56.
M2616—a high performance multi-line telephone with 16 programmable
function keys and integrated Handsfree unit. See
M2016S—a Telephone Security Group Class II approved telephone designed
to provide on-hook security. It is similar to the M2616, with 16
programmable function keys, but has no handsfree capability. See
on page 57.
M2216ACD-1—a multi-line telephone for ACD operations. It has 15
programmable function keys, a special ACD Display Module and two
RJ-32 jacks for modular electret headsets. See
M2216ACD-2—a multi-line telephone for ACD operations. It has 15
programmable function keys, and a special ACD Display. It is similar to
model 1, but with one PJ-327 jack for a carbon agent headset and one RJ-32
jack for an electret supervisor headset. See
September 1998
55.
Figure 7 on page
Figure 8 on page
Figure 8 on page 58.
57.
Figure 7
58.
