System GM32 Standard

8012707/ZVF9/V2-1/2019-04 | SICK
Subject to change without notice
Description
Measured variable
TÜV tested measured variable NO, SO2
Maximum number of
measured variables
Measuring principle
Measuring ranges
Certified measuring ranges
Response time (t )
90
Precision
Ambient temperature
Storage temperature
Ambient humidity
Conformities
Electrical safety
Table 20: Technical data GM32 system standard Probe version
Performance-tested in-situ-gas analyzer
NO, NO , NH , SO
2 3 2
4 (plus process temperature and pressure).
Differential Optical Absorption Spectroscopy (DOAS)
NH : 0 ... 30 ppm / 0 ... 2,600 ppm (+/- 2% of FS)
3
NO: 0 ... 40 ppm / 0 ... 1.900 ppm (+/- 2% of FS)
NO : 0 ... 50 ppm / 0 ... 1,000 ppm (+/- 2% of FS)
2
LowNO (Option): 0 ... 15 ppm/ 0 ... 1,000 ppm (+/- 2% of FS)
2
SO : 0 ... 15 ppm / 0 ... 7,000 ppm (+/- 2% of FS)
2
Measuring ranges refer to 1 m measuring path
Measuring ranges depending on application and device version
Caution: Specification refers to:
- Dust-free gas
- No cross-sensitivities
- Gas temperature: 70°C
NO: 0 ... 70 mg/m 3 / 0 ... 700 mg/m
SO2: 0 ... 75 mg/m 3 / 0 ... 1,000 mg/m
With an active measuring path length of 1.25 m (GMP measuring probe).
The measuring probe (GPP) which can be gas tested is not TÜV
performance tested.
LowNOx version
● NO: Certification range: 0 ... 70 mg/m
● SO2: Certification range: 0 ... 75 mg/m
For an active measuring path of 1 m (GMP measuring probe)
The gas testable measuring probe (GPP) is not TÜV performance
tested
GMP measuring probe: ≥ 5 s, adjustable
Gas-testable measuring probe (GPP): ≥ 120 s, adjustable
TÜV performance test: ≥ 30 s, adjustable
NH : ≥ 0.7 ppm
3
NO: ≥ 0.8 ppm
NO : ≥ 2.5 ppm
2
SO : ≥ 0.3 ppm
2
Relative to the smallest measuring range
–20 °C ... +55 °C
Temperature change max. ±10 °C/h
–20 °C ... +55 °C
Temperature change max. ±10 °C/h
≤ 96%
Relative humidity; moisture condensation on optical interfaces not
allowed.
Approved for plants requiring approval:
2001/80/EC (13th BImSchV)
2000/76/EC (17th BImSchV)
27th BImSchV
TI Air
EN 15267
EN 14181
MCERTS
GOST
CE
