N E W P O RT P L AY S E T – F 2 9 0 1 5

INSTALLATION AND OPERATING INSTRUCTIONS

13'1"

26'0"

10'2"

25'1"

KidKraft, Inc.

4630 Olin Road

Dallas, Texas 75244 USA

customerservice@kidkraft.com

canadacustomerservice@kidkraft.com

1.800.933.0771

972.385.0100

For online parts replacement visit

https://parts.kidkraft.com/

WARNING

Spring Meadow

Swing Set

Manufacturer contact information provided below.

OBSTACLE FREE SAFETY ZONE - 25'1" x 26' area requires Protective Surfacing. See page 3.

MAXIMUM VERTICAL FALL HEIGHT - 6' (1.8 m)

CAPACITY - 9 Users Maximum, Ages 3 to 10; Weight Limit 110 lbs. (49.9 kg) per child.RESIDENTIAL HOME USE

ONLY. Not intended for public areas such as multi-unit residences, schools, churches, nurseries, day cares or

parks.

KidKraft Netherlands BV

Olympisch Stadion 29

1076DE Amsterdam

The Netherlands

europecustomerservice@kidkraft.com

+31 20 305 8620 M-F from 09:00 to 17:30

(GMT+1)

For online parts replacement visit

https://parts.kidkraft.eu/

To reduce the risk of serious injury or death, you must read and

follow these instructions. Keep and refer to these instructions

often and give them to any future owner of this play set.

Warnings And Safe Play Instructions . . . . . . . . . . pg . 2

Protective Surfacing Guidelines . . . . . . . . . . . . . . . pg . 3

Instructions For Proper Maintenance . . . . . . . . . pg . 4

About Our Wood – Limited Warranty . . . . . . . . . pg . 5

Keys To Assembly Success . . . . . . . . . . . . . . . . . . . . pg . 7

Part ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pg . 8

Step-By-Step Instructions . . . . . . . . . . . . . . . . . . .pg . 14

Installation of ID/Warning Plaque . . . . . . . . . . .pg . 55

9409015

10 - 12 Hrs

2-4 Hrs

4 - 8 Hrs

FOR FORT & SWING

TWO PERSON

ASSEMBLY

Rev 06/11/2018

Table of Contents
