12.4 EXTERNAL DIMENsIONs

CJC SENSOR

(model: CJM)

* Used only with a thermocouple input

10 11 12

18 (.71)

110.5 (4.35)

• When mounting, no extra space is needed between units

M3LU2 OPERATING MANUAL EM-2653-B Rev.0

mm (inch)

DIN RAIL

35mm wide

[5 (.20)]
