10.2.2 MAXIMUM RANGE, MINIMUM sPAN AND DEFAULT VALUE OF INPUT

The maximum range, minimum span and default value of the input are shown in the following tables. The default value
means initial 0% and 100% input when the DIP switch setting is changed.
10.2.2.1 DC current input
MAXIMUM RANGE
0 to 20 mA DC
10.2.2.2 DC voltage input (mV)
MAXIMUM RANGE
-1000 to +1000 mV DC
10.2.2.3 DC voltage input (V)
MAXIMUM RANGE
-10 to +10 V DC
10.2.2.4 Thermocouple input
Minimum span: 20°C (36°F)
Default value: same as conformance range in °C
THERMOCOUPLE °C
MAXIMUM RANGE
(PR) 0 to 1760
K (CA) -270 to +1370
E (CRC) -270 to +1000
J (IC) -210 to +1200
T (CC) -270 to +400
B (RH) 100 to 1820
R -50 to +1760
S -50 to +1760
C (WRe 5-26) 0 to 2315
N -270 to +1300
U -200 to +600
L -200 to +900
P (Platinel II) 0 to 1395
MINIMUM SPAN
1 mA
MINIMUM SPAN
4 mV
MINIMUM SPAN
1 V
CONFORMANCE RANGE MAXIMUM RANGE
0 to 1760
-150 to +1370
-170 to +1000
-180 to +1200
-170 to +400
400 to 1760
200 to 1760
0 to 1760
0 to 2315
-130 to +1300
-200 to +600
-200 to +900
0 to 1395
DEFAULT VALUE
4 to 20 mA DC
DEFAULT VALUE
0 to 1000 mV DC
DEFAULT VALUE
1 to 5 V DC
°F
32 to 3200
-454 to +2498
-454 to +1832
-346 to +2192
-454 to +752
212 to 3308
-58 to +3200
-58 to +3200
32 to 4199
-454 to +2372
-328 to +1112
-328 to +1652
32 to 2543
M3LU2 OPERATING MANUAL EM-2653-B Rev.0
CONFORMANCE RANGE
32 to 3200
-238 to +2498
-274 to +1832
-292 to +2192
-274 to +752
752 to 3200
392 to 3200
32 to 3200
32 to 4199
-202 to +2372
-328 to +1112
-328 to +1652
32 to 2543
31
