12.1.3 OUTPUT sPECIFICATIONs

Output types and ranges are shown in the following table.
DC Current
DC Voltage

12.1.4 INsTALLATION

Power comsumption AC power
DC power
Operating temperature
Operating humidity
Mounting
Weight

12.1.5 PERFORMANCE

Accuracy
Cold junction compensation error
Temp. coefficient
Response time
Burnout response
Line voltage effect
Insulation resistance
Dielectric strength
Maximum range: 0 – 20 mA DC
Minimum span: 1 mA
Conformance range: 0 – 23 mA DC
Offset: Lower range can be any specific value within the output range provided
that the minimum span is maintained.
Load resistance: Output drive 15 V max. at 20 mA
(Range: Load resistance)
0 – 20 mA : ≤ 750 Ω
Narrow spans
Maximum range: -2.5 – +2.5 V DC
Minimum span: 250 mV
Conformance range: -3 – +3 V DC
Wide spans
Maximum range: -10 – +10 V DC
Minimum span: 1 V
Conformance range: -11.5 – +11.5 V DC
Offset: Lower range can be any specific value within the output range provided
that the minimum span is maintained.
Load resistance: Output drive 10 mA max.; 5 mA for negative output
(Range: Load resistance)
0 – 10 V : ≥ 1 kΩ
-10 – 0 V : ≥ 2 kΩ
0 – 2.5 V : ≥ 250 Ω
-2.5 – 0 V : ≥ 500 Ω
M2: 100 – 240 V AC Operational voltage range 85 – 264 V AC, 47 – 66 Hz
Approx. 4 VA at 100 V
Approx. 5 VA at 200 V
Approx. 6 VA at 264 V
R4: 10 – 32 V DC Operational voltage range 9 – 36 V DC
Ripple 10% p-p max.
Approx. 3 W
-25 to +60°C (-13 to +140°F)
30 to 95% RH (non-condensing)
DIN rail
100 g (3.53 oz)
See Table 1 to 6.
±1.0°C at 0 – 50°C (±1.8°F at 32 – 122°F)
±0.015%/°C [±0.008%/°F] at -5 to +55°C [23 to 131°F] of max. range
±0.03%/°C [±0.016%/°F] for the following conditions:
• DC, T/C input spans ≤ 10 mV
• RTD, potentiometer, resistance spans ≤ 80 Ω
• in an ambient exceeding 55°C [131°F] or below -5°C [23°F]
≤ 0.2 sec. (0 – 90%, DC input)
(With the Option A, the Sync Filter set to the fastest frequency on the PC Configu-
rator Software. Default is set to have 0.5 sec. response.)
≤ 10 sec.
±0.1% over voltage range
≥ 100 MΩ with 500 V DC
2000 V AC @ 1 minute (input to output to power to ground)
