12. APPENDICEs

12.1 sPECIFICATIONs

12.1.1 GENERAL sPECIFICATIONs

Construction
Connection
Housing material
Isolation
Overrange output
Zero adjustment
Span adjustment
Burnout (other than current or voltage (V) input)
Linearization (T/C, RTD input)
Cold junction compensation (T/C input)
Status indicator LED
Configuration DIP SW configuration
PC configuration
Calibration
Configurator connection

12.1.2 INPUT sPECIFICATIONs

Input types and ranges are shown in the following table.
DC Current
mV & Voltage
Thermocouple
RTD (2-wire, 3-wire or 4-wire)
Resistance (2-wire, 3-wire or 4-wire)
Potentiometer
Small-sized front terminal structure
Euro type connector terminal
Flame-resistant resin (gray)
Input to output to power
-15 to +115% (negative current output is not available)
-15 to +15% (front)
85 to 115% (front)
Upscale, downscale or no burnout selectable; Also detects wire breakdown and
overrange input exceeding the electrical design limit for DC input.
Standard
CJC sensor (included) to be attached to the input terminals
Tri-color (green/amber/red) LED; Blinking patterns indicate operation status of the
transmitter.
Input type, sensor type, burnout action, RTD/resistance wires, cold junction com-
pensation, output type, configuration mode, front control button lock
Refer to 12.2 PC CONFIGURATOR SOFTWARE.
I/O ranging and fine adjustment via 'One-Step Cal' calibration or PC
2.5 dia. miniature jack; RS-232-C level
Input resistance: 50 Ω resistor incorporated
Maximum range: 0 to 20 mA DC
Minimum span: 1 mA
Input resistance: ≥ 1 MΩ
Maximum range: refer to Table 1
Minimum span: refer to Table 1
Input resistance: ≥ 1 MΩ
Maximum range: refer to Table 2
Burnout sensing: ≤ 4 µA
Conformance range: refer to Table 2
Minimum span: refer to Table 2
Excitation: ≤ 0.3 mA
Maximum range: refer to Table 3
Allowable leadwire resistance: max. 20 Ω per wire
Minimum span: refer to Table 3
Excitation: ≤ 0.3 mA
Maximum range: 0 to 4000 Ω
Allowable leadwire resistance: max. 20 Ω per wire
Minimum span: 10 Ω
Excitation: ≤ 0.3 mA
Maximum range: refer to Table 5
Allowable leadwire resistance: max. 20 Ω per wire
Minimum span: 2%
