12.2 PC CONFIGURATOR sOFTWARE

The I/O settings and calibration are configurable with the PC Configurator Software (model: M3LUCFG). It is convenient
to set the same I/O specifications to several units or the items which are not available with the DIP SW configuration or
'One-Step Cal' calibration. Whether the I/O settings are available or not depends on the configuration option code and
configuration mode.
A dedicated cable is required to connect the unit to the PC.
PORT
RS-232-C
USB
The PC Configurator Software is freely downloadable at M-System's web site (http://www.m-system.co.jp/).
Software download model No.: M3CFG
■ I/O CONFIGURATION
The following table shows configurable items with the PC Configurator Software. For detailed information on the PC con-
figuration, refer to the M3LUCFG users manual (EM-9197-A).
ITEM
Input type
Sensor wires
PV range (upper, lower)
PV damping (time constant)
Burnout
Cold junction compensation
Transfer function
AO type
AO range (upper, lower)
ADC conversion rate
Custom TC
Custom RTD
Linearization table setting
■ CALIBRATION
'One-Step Cal' calibration (I/O ranging) and DAC trimming (fine adjustments) are configurable with the PC Configurator
Software regardless of the configuration option code and configuration mode.
■ REMARKs
For detailed information on the PC configuration, refer to the M3LUCFG users manual (EM-9197-A).
PC CONFIGURATOR CABLE MODEL NO.
MCN-CON
COP-US
M3LU2-x/A
PC CONFIGURATION
(SW3-8 ON)
X
X
X
X
X
X
X
X
X
X
X
X
X
DIP SW CONFIGURATION
(SW3-8 OFF)
----
----
----
X
----
----
X
----
----
X
----
----
X
