7.2.1 CONFIGURATION MODE

With the model M3LU2-x/A, select the configuration mode (configuration method of I/O specifications), DIP SW configura-
tion or PC configuration, as shown in the following table. With the model M3LU2-x/B, turn the SW3-8 OFF.
DIP SW configuration: sets I/O specifications with the DIP switches inside the cover and the front control buttons.
PC configuration: sets I/O specifications with the PC Configurator Software (model: M3LUCFG).
MODE SW3-8
DIP SW OFF
PC ON

7.2.2 INPUT TYPE (JP2)

Switch the JP2 jumper according to the input specifications.
Note that the JP2 setting is required with the PC configuration.
DC VOLTAGE [V] RANGE POSITION
[maximum range: -10 to +10 V DC]
1 2 3
Switch the JP2 jumper to the 2-3 position.

7.2.3 INPUT (DIP sWITCHEs)

Set the DIP switches (SW2-1 through 2-5, SW3-1 through 3-7) according to the input specifications. These settings are not
required with the PC configuration.
7.2.3.1 DC current input
SW3-7 SW3-6
OFF OFF
SW2-5 SW2-4
OFF OFF
7.2.3.2 DC voltage input (mV) [maximum range: -1000 to +1000 mV DC]
SW3-7 SW3-6
OFF OFF
SW2-5 SW2-4
Refer to Burnout
• Burnout
BURNOUT
No burnout
Upscale
Downscale
NORMAL POSITION
(other than DC voltage [V] range)
Jumper
Switch the JP2 jumper to the 1-2 position.
SW3-5 SW3-4
OFF OFF
SW2-3 SW2-2
OFF OFF
SW3-5 SW3-4
ON OFF
SW2-3 SW2-2
OFF OFF
SW2-5 SW2-4
OFF OFF
OFF ON
ON ON
Jumper
1 2 3
SW3-3 SW3-2
OFF OFF
SW2-1
OFF
SW3-3 SW3-2
OFF OFF
SW2-1
OFF
M3LU2 OPERATING MANUAL EM-2653-B Rev.0
SW3-1
OFF
SW3-1
OFF
16
