7.2.4 OUTPUT TYPE

Set the DIP switches (SW1-1 through 1-4, SW2-7 and 2-8) according to the output specifications.
The DIP switch settings (SW1-1 through 1-4) are required with the PC configuration.
7.2.4.1 DIP sW configuration
• DC current output
SW1-4 SW1-3
OFF ON
• DC voltage output (narrow spans) [maximum range: -2.5 to +2.5 V DC]
SW1-4 SW1-3
ON OFF
• DC voltage output (wide spans) [maximum range: -10 to +10 V DC]
SW1-4 SW1-3
ON OFF
7.2.4.2 PC configuration
• DC current output
SW1-4 SW1-3
OFF ON
• DC voltage output (narrow spans) [maximum range: -2.5 to +2.5 V DC]
SW1-4 SW1-3
ON OFF
• DC voltage output (wide spans) [maximum range: -10 to +10 V DC]
SW1-4 SW1-3
ON OFF

7.2.5 FRONT CONTROL BUTTON LOCK

You can lock the button operation on the front panel to prevent inadvertent operation.
LOCK SW2-6
Unlock OFF
Lock ON
SW1-2 SW1-1
OFF OFF
SW1-2 SW1-1
OFF ON
SW1-2 SW1-1
ON OFF
SW1-2 SW1-1
OFF OFF
SW1-2 SW1-1
OFF ON
SW1-2 SW1-1
ON OFF
SW2-8 SW2-7
OFF OFF
SW2-8 SW2-7
OFF ON
SW2-8 SW2-7
ON OFF
