10.2.2.5 RTD input
Minimum span: 20°C (36°F)
Default value: same as maximum range in °C
RTD
Pt 100 (JIS '97, IEC)
Pt 200
Pt 300
Pt 400
Pt 500
Pt 1000
Pt 50 Ω (JIS '81)
JPt 100 (JIS '89)
Ni 100
Ni 120
Ni 508.4 Ω
Ni-Fe 604
Cu 10 @25°C
10.2.2.6 Resistance input
MAXIMUM RANGE
0 to 4000 Ω
10.2.2.7 Potentiometer input
MAXIMUM RANGE
(TOTAL RESISTANCE)
2500 to 4000 Ω
1200 to 2500 Ω
600 to 1200 Ω
300 to 600 Ω
150 to 300 Ω
80 to 150 Ω

10.2.3 MAXIMUM RANGE, MINIMUM sPAN AND DEFAULT VALUE OF OUTPUT

The maximum range, minimum span and default value of the output are shown in the following tables. The default value
means initial 0% and 100% output when the DIP switch setting is changed.
10.2.3.1 DC current output
MAXIMUM RANGE
0 to 20 mA DC
10.2.3.2 DC voltage output (narrow spans)
MAXIMUM RANGE
-2.5 to +2.5 V DC
10.2.3.3 DC voltage output (wide spans)
MAXIMUM RANGE
-10 to +10 V DC
°C
MAXIMUM RANGE
-200 to +850
-200 to +850
-200 to +850
-200 to +850
-200 to +850
-200 to +850
-200 to +649
-200 to +510
-80 to +260
-80 to +260
-50 to +200
-200 to +200
-50 to +250
MINIMUM SPAN
10 Ω
MINIMUM SPAN
2% of total resistance
MINIMUM SPAN
1 mA
MINIMUM SPAN
250 mV
MINIMUM SPAN
1 V
°F
MAXIMUM RANGE
-328 to +1562
-328 to +1562
-328 to +1562
-328 to +1562
-328 to +1562
-328 to +1562
-328 to +1200
-328 to +950
-112 to +500
-112 to +500
-58 to +392
-328 to +392
-58 to +482
DEFAULT VALUE
0 to 4000 Ω
DEFAULT VALUE
0 to 100%
DEFAULT VALUE
4 to 20 mA DC
DEFAULT VALUE
0 to 1 V DC
DEFAULT VALUE
1 to 5 V DC
M3LU2 OPERATING MANUAL EM-2653-B Rev.0 32
