SENSOR INSTALLATION FAULTS
simulates a medium wet material and with the black rubber face in contact with the
ceramic plate simulates a very wet material.
68
HYDRO-VIEW USER GUIDE D0022 REV 1.06
Block 1
Block 2 (Rubber Face Up)
Block 3 (Rubber Face Down)
• Figure 30 : Using test blocks
8.9v
5.0v
1.7v
