SENSOR CONNECTIONS – HYDRO-PROBE I

Digital input connections

The two digital inputs (terminals 14 & 15) share a single common terminal (16) and are
arranged internally as shown in Figure 25.
Terminals 13 and 17 are connected to an internal dc power supply which may be used as
an excitation supply for voltage-free contacts if required as shown in Figure 26.
60
HYDRO-VIEW USER GUIDE D0022 REV 1.06

• Figure 24 - Analogue output wiring
