TREND DISPLAY PAGE
The current value of the variable whose trace is being displayed is shown at the top left
hand corner of the display.
For clarity on the small display, the vertical axis is not labelled. However, the traces are
scaled according to the values programmed in the Sensor set-up menu.
You can select the trend display from any non-menu display page using the following
keys...
⇒ Press
⇒ Press
⇒ Press
Once the record option has been chosen, the most recent 100 values will be recorded
continuously until the pause option is chosen, even if another display page is selected in
the meantime.
You can adjust how often a reading is taken by the trend display from the Sensor set-up
menu.
26
HYDRO-VIEW USER GUIDE D0022 REV 1.06
to display the Main menu. The moisture display item is highlighted.
to highlight the trend display item.
again to select the trend display page.

• Figure 8 - Trend display
