SUGGESTED WORKING VALUES

Suggested working values
The example configurations given in this section should be used as a guide in developing
your own systems. However, the applications of the Hydro-View are not limited to these
applications. The examples show the minimum configurations required and in general do
not show variations in the use of interfacing techniques, each of which is described
elsewhere.
The following tables give recommended working values for the three examples described
in Applications of Hydro-View with Hydronix moisture sensors (p10). These should be
treated as starting points, although in practice very little tuning should be required. These
values will need to be adjusted to suit changes to interfacing arrangements which may
have been employed.

Sensor set-up

Parameter name
Type
Samples
A/H delay
Sync delay
+dV Coarse
-dV Coarse
+dV Fine
-dV Fine
Minimum volts
Maximum volts
Trend step (s)
Trend lower %
Trend upper %
Alarm Lo %
Alarm Hi %

Output set-up

Parameter name
Minimum %
Maximum %
Calibrate %
Variable

Sensor calibration

Parameter name
Unscaled i/p 1
Moisture % 1
Unscaled i/p 2
Moisture % 2
SSD %
1
Depends on rotational speed of mixer. This is three rotations at 2.5 seconds.
2
Depends on time constants in feedback control system. This will give a response time of around 10 seconds.
3
Normally set to reflect the absorption properties of material in ready-mix applications.
40
HYDRO-VIEW USER GUIDE D0022 REV 1.06
Batch weigher Batch mixer
1 1
1
5 75
0.5 0
0.00 0.00
1.00 0.02
1.00 0.05
0.10 0.01
0.10 0.02
0.5V 0.5
12.0V 12.0
1.0 1.0
0.00 0.00
20.00 20.00
0.00 0.00
20.00 20.00
Batch weigher Batch mixer
0.00 0.00
20.00 20.00
0.00 0.00
AVERAGE NOW
Batch weigher Batch mixer
4.15 4.15
0.00 0.00
28.40 28.40
11.00 11.00
3
0.00 0.00
Continuous
process
1
2
100
0
0.00
0.02
0.02
0.02
0.02
0.5
12.0
1.0
0.00
20.00
0.00
20.00
Continuous
process
0.00
20.00
0.00
NOW
Continuous
process
4.15
0.00
28.40
11.00
0.00
