Esd Notes - SimCom SIM7020C Hardware Design

eDRX mode supply current
（Tested in sleep mode）
LTE data
LTE-FDD B1
LTE-FDD B3
LTE-FDD B5
LTE-FDD B8
LTE-FDD B20
LTE-FDD B28
5.5

ESD Notes

SIM7020 is sensitive to ESD in the process of storage, transporting, and assembling. When SIM7020
is mounted on the users' mother board, the ESD components should be placed beside the connectors
which human body may touch, such as SIM card holder, audio jacks, switches, keys, etc. The
following table shows the SIM7020 ESD measurement performance without any external ESD
component.
Table 31: The ESD performance measurement table
Part
GND
（Shield）
GND
（RF）
VBAT
Antenna port
Other PADs
Note: Temperature: 25
SIM7020_Hardware_Design_V1.02
@PTW=10.24s,
Typical：230uA
@PTW=10.24s,
Typical：130uA
@PTW=20.48s,
Typical：95uA
@PTW=20.48s,
Typical：77.5uA
@PTW=40.96s,
Typical：69uA
@23dbm Typical: 134mA
@10dbm Typical: 42mA
@0dbm Typical: 32mA
@23dbm Typical: 116mA
@10dbm Typical: 44mA
@0dbm Typical: 31 mA
@23dbm Typical: 116mA
@10dbm Typical: 35mA
@0dbm Typical: 25mA
@23dbm Typical: 128mA
@10dbm Typical: 35mA
@0dbm Typical: 25mA
@23dbm Typical: 113mA
@10dbm Typical: 34mA
@0dbm Typical: 26mA
@23dbm Typical: 126mA
@10dbm Typical: 38mA
@0dbm Typical: 27mA
Contact discharge(kV)
+/-6
+/-6
+/-5
+/-5
+/-3
, Humidity: 45%, tested on SIMCOM-EVB.
℃
eDRX=20.48s,
eDRX=20.48s,
eDRX=81.92s,
eDRX=162.84s,
eDRX=655.36s,
38
Smart Machine Smart Decision
DRX=1.28s
DRX=2.56s
DRX=2.56s
DRX=2.56s
DRX=2.56s
Air discharge(kV)
+/-12
+/-12
+/-10
+/-10
+/-6
2018-07-25
