Lte Antenna Design Guide - SimCom SIM7020C Hardware Design

3 1710 ~1785 MHz
5 824 ~849 MHz
6 830 ~840 MHz
8 880 ~915 MHz
12 699 ~716 MHz
13 777 ~787 MHz
18 815 ~830 MHz
19 830 ~845 MHz
20 832 ~862 MHz
26 814 ~849 MHz
28 703 ~748 MHz
Table 21: CAT-NB1 Reference sensitivity (QPSK)
Operating band
1, 3,5, 8, 20, 28
4.2

LTE Antenna Design Guide

Users should connect antennas to SIM7000's antenna pads through micro-strip line or other types of
RF trace and the trace impedance must be controlled in 50Ω.SIMCom recommends that the total
insertion loss between the antenna pads and antennas should meet the following requirements:
Table 22: Trace loss
Frequency
700MHz-960MHz
1710MHz-2170MHz
2300MHz-2650MHz
To facilitate the antenna tuning and certification test, a RF connector and an antenna matching circuit
should be added. The following figure is the recommended circuit.
SIM7020_Hardware_Design_V1.02
1805 ~1880 MHz
869 ~894 MHz
875 ~885 MHz
925 ~960 MHz
729 ~746 MHz
746 ~756 MHz
860 ~875 MHz
875 ~890 MHz
791 ~821 MHz
859 ~894 MHz
758 ~803 MHz
Sensitivity dBm (95% throughput with
repetitions )
-131
Loss
<0.5dB
<0.9dB
<1.2dB
30
Smart Machine Smart Decision
HD-FDD
HD-FDD
HD-FDD
HD-FDD
HD-FDD
HD-FDD
HD-FDD
HD-FDD
HD-FDD
HD-FDD
HD-FDD
2018-07-25
