Transition Networks DataBand EV User Manual page 9

Any equipment which is connected to a Patapsco system should be separately approved for connection.
Port Safety Status
ISDN Network Ports - TNV
Term and LAN Ports - SELV
Mains Connection (AC)
The power requirements for DataBand EV are: 95VAC to 240VAC at 47-63Hz.
The Mains Plug should conform to: EL-302 to Nema 5-15P class 1 applications 10/15 A @ 125V 10A minimum >28AWG
The IEC Plug conforms to: El-701A to IEC320/C13 10A 250V rating.
The following rated mains cables must be used in the regions stated:
Region
Europe
United Kingdom
USA/Canada
Australia
South Africa
International
DC Connection
Unit may be fitted with a DC power inlet. The DC voltage connected should be in the range 36-70VDC. Typically 400mA @ 48VDC.
TDM Connections
TDM cables used should meet the following specifications:
24AWG 0.2mm/7 stranded bare copper 3 or 4 pairs dependent
Shielded or Non-Shielded with moulded US plug 8P8C gold plated 3U
European Deviations
S (FI, NO, SE) CLASS 1 PLUGGABLE EQUIPMENT TYPE A
Intended for connection to other equipment or a network shall, if safety relies on connection to protective earth or if surge suppressors
are connected between the network terminals and accessible parts, have a marking stating that the equipment must be connected to
an earthed mains socket-outlet.
The marking text in the applicable countries shall be as follows:
© 2012 Patapsco Designs Ltd
Standard Rated Current ( Amps)
CEE(7) VII
BS1363A
5-15P
AS 3112
BS546
IEC 320/C13-C15
Rated Voltage ( Volts)
10
13
10
10
10
10 125/250
Safety
Application
250 Class 1 Appliances
250 Class 1 Appliances
125 Class 1 Appliances
250 Class 1 Appliances
250 Class 1 Appliances
Class 1 Appliances
