5.4. Cable Spec

Specs for cables used with all Patapsco products are shown. The polarity of all connections is written from the point of view of a
cable connecting to the Patapsco unit.
Double-click on the cable names below to open the spec for each cable. The colour of the text corresponds to the colour supplied
by Patapsco.

5.5. Installing DbManager

Note: If you have an older DbManager installation on the management PC already, it is possible to upgrade to
the version of DbManager on the CD. A batch file on the CD can be used to do this automatically provided the
application is installed in the default location (C:\Program Files\Patapsco\DbMgr). Please see the Upgrade
folder on the installation disk for details. Upgrading to the latest version of DbManager is always recommended.
Please follow these steps to install DbMgr:
1. Insert the DbMgr disk into your CD drive. The installation will start. Read the license agreement and click N ext >
2. Fill out the Customer Information form. If the version of DbMgr purchased is a multi-user and/or multi-device version, there
will be a serial number on the case for the DbMgr disk. Enter the serial number.
Note: If there is no serial number on the case, the DbMgr is a Lite version. Please leave the Serial Number field
blank.
3. Choose a location to install DbMgr to and continue the installation.
4. DbMgr is now installed and ready to use.
© 2012 Patapsco Designs Ltd
Controller
Ethernet
Ethernet Crossover
TDM
TDM Crossover
V.35
X.21
V.35/X.21
