How to Programme
6.4 Quick Transfer of Parameter Settings
between Multiple Frequency Converters
Once the set-up of a frequency converter is complete,
Danfoss recommends that you store the data in the LCP or
on a PC via MCT 10 Set-up Software tool.
Data storage in LCP.
1. Go to 0-50 LCP Copy
2. Press the [OK] key
3. Select "All to LCP"
6 6
4. Press the [OK] key
WARNING
Stop the motor before performing this operation.
You can now connect the LCP to another frequency
converter and copy the parameter settings to this
frequency converter as well.
Data transfer from LCP to frequency converter:
1. Go to 0-50 LCP Copy
2. Press the [OK] key
3. Select "All from LCP"
4. Press the [OK] key
NOTE
Stop the motor before performing this operation.
6.5 Read-out and Programming of Indexed
Parameters
Use 3-10 Preset Reference as an example.
Choose the parameter, press [OK], and use the up/down
navigation keys to scroll through the indexed values. To
change the parameter value, select the indexed value and
press [OK]. Change the value by using the up/down keys.
Press [OK] to accept the new setting. Press [CANCEL] to
abort. Press [Back] to leave the parameter.
62
VLT HVAC Basic Drive Design Guide
6.6 Initialise the Frequency Converter to
Recommended initialisation (via 14-22 Operation Mode)
1.
2.
3.
4.
5.
®
MG.18.C2.02 - VLT is a registered Danfoss trademark
Default Settings in two Ways
Select 14-22 Operation Mode.
Press [OK].
Select Initialisation and Press [OK].
Cut off the mains supply and wait until the
display turns off.
Reconnect the mains supply - the frequency
converter is now reset. Except the following
parameters.
8-30 Protocol
8-31 Address
8-32 Baud Rate
8-33 Parity / Stop Bits
8-35 Minimum Response Delay
8-36 Maximum Response Delay
8-37 Maximum Inter-char delay
8-70 BACnet Device Instance
8-72 MS/TP Max Masters
8-73 MS/TP Max Info Frames
8-74 "I am" Service
8-75 Intialisation Password
15-00 Operating Hours to 15-05 Over Volt's
15-03 Power Up's
15-04 Over Temp's
15-05 Over Volt's
15-30 Alarm Log: Error Code
15-4* Drive identification parameters
1-06 Clockwise Direction
