General Specifications and ...
Analog inputs
Number of analog inputs
Terminal number
Terminal 53 mode
Terminal 54 mode
Voltage level
Input resistance, R
i
Max. voltage
Current level
Input resistance, R
i
Max. current
Analog output
Number of programmable analog outputs
Terminal number
Current range at analog output
Max. load to common at analog output
Max. voltage at analog output
Accuracy on analog output
Resolution on analog output
1) Terminal 42 and 45 can also be programmed as digital outputs.
Digital output
Number of digital outputs
Terminal number
Voltage level at digital output
Max. output current at digital output
Max. load at digital output
1) Terminals 42 and 45 can also be programmed as analog output.
Control card, RS-485 serial communication
Terminal number
Terminal number
Control card, 24V DC output:
Terminal number
Max. load enclosure frame H1-H8
Relay output
Programmable relay output
Relay 01 and 02
1)
Max. terminal load (AC-1) on 01-02/04-05 (NO) (Resistive load)
Max. terminal load (AC-15) 1) on 01-02/04-05 (NO) (Inductive load @ cosφ 0.4)
Max. terminal load (DC-1) 1) on 01-02/04-05 (NO) (Resistive load)
1)
Max. terminal load (DC-13) on 01-02/04-05 (NO) (Inductive load)
1)
Max. terminal load (AC-1) on 01-03/04-06 (NC) (Resistive load)
Max. terminal load (AC-15) 1) on 01-03/04-06 (NC) (Inductive load @ cosφ 0.4)
Max. terminal load (DC-1) 1) on 01-03/04-06 (NC)
(Resistive load)
Environment according to EN 60664-1
1) IEC 60947 parts 4 and 5.
Control card, 10V DC output
Terminal number
Output voltage
Max. load
VLT HVAC Basic Drive Design Guide
Min. terminal load on 01-03 (NC), 01-02 (NO) 24V DC 10mA, 24V AC 20mA
®
MG.18.C2.02 - VLT is a registered Danfoss trademark
Parameter 6-19: 1 = voltage, 0 = current
Parameter 6-29: 1 = voltage, 0= current
0/4 to 20mA (scalable)
Max. error: 0.4% of full scale
68 (P, TX+, RX+), 69 (N, TX-, RX-)
61 Common for terminals 68 and 69
01-03 (NC), 01-02 (NO), 04-06 (NC), 04-05 (NO)
Overvoltage category III/pollution degree 2
2
53, 54
0 - 10V
approx. 10kΩ
20V
<500Ω
29mA
2
1)
42, 45
0/4 - 20mA
500Ω
17V
12 bit
8 8
2
42, 45 1)
17V
20mA
1kΩ
12
80mA
2
250V AC, 3A
250V AC, 0.2A
30V DC, 2A
24V DC, 0.1A
250V AC, 3A
250V AC, 0.2A
30V DC, 2A
50
10.5V ±0.5V
25mA
