Danfoss VLT HVAC Basic Drive FC 100 Series Design Manual page 53

How to Install
5 5
PLC
Mains-supply
L1
L2
L3
PE
Reinforced protective earth
Illustration 5.1 EMC-correct Electrical Installation
For North America use metal conduits instead of shielded cables.
52
PLC etc.
2
Min. 16 mm
Equalizing cable
Control cables
Min. 200mm
between control
cable, mains cable
and between mains
motor cable
MG.18.C2.02 - VLT
VLT HVAC Basic Drive Design Guide
Panel
®
is a registered Danfoss trademark
Output con-
tactor etc.
Earthing rail
Cable insula-
tion stripped
All cable entries in
one side of panel
Motor cable
Motor, 3 phases and
Protective earth
