Tektronix WFM5200 Series Release Notes page 4

Release notes
Waveform display
Figure 1: Waveform display pop-up menu showing the Dynamic Range selection
2
Dynamic Range setting. The pop-up menu for the Waveform display now
contains a selection for setting the Dynamic Range as shown below (Option
PROD required).
NOTE.
When HDR, HDR Full, SDR Narrow, or SDR Full is selected, you can use
the Left / Right arrow keys to toggle the vertical scale of the graticule between
NITS, STOPS, REFLECTANCE, CODE VALUE, and PERCENT. The selected
scale is shown at the bottom of the display. (See Figure 3.)
WFM5200 Series and WVR5200 Series Release Notes
