General limitations

External reference
Frozen frame detection
(WFM5250 and WVR5250
models only)
HDMI format (WFM5250
and WVR5250 models
only)
Incompatible operation
Line select
Remote web user interface
SDI output (WFM5250 and
WVR5250 models only)
Sweep
WFM5200 Series and WVR5200 Series Release Notes
This release has the following general limitations for all instrument models, unless
otherwise noted. Topics are listed in alphabetical order.
The waveform display may take up to 10 seconds to stabilize with external
Tri-level sync.
Frozen Frames for HDMI 1080p 50/59.94 are calculated using odd lines on frame
n and even lines on frame n+1.
480i and 576i formats are not officially supported for HDMI inputs.
When applying 3 Gb/s signals to any instrument that does not support the
signal formats, the unit indicates that the signal input is not standard. Applying
unsupported video signals may result in a frozen PICT display.
Internal reference should be used with line select operation for 3G-SDI Level A
signals.
When the external reference has Tri-level sync, the format readout from the
remote web user interface may not be reliable.
SDI output in Pix monitor mode has no signal output when the input signal has a
480i/576i/480p/576p and 640 x 480 format through an HDMI input.
The waveform style must be set to Overlay to get 2 line or 2 field sweep.
USB
Always press the MAIN button and select USB Status to safely "Unmount"
and remove the USB memory device from the USB port. You risk permanent
loss of any files saved on the USB device if you do not use the "Unmount"
feature.
If there are more than 32 files saved in a Presets directory on the USB device,
you can only view the first 32 files.
