Release notes
Typical HDR
monitoring setup for
ST2084(10K)
Figure 5: Typical HDR monitoring setup for ST2084(10K)
For more information visit:
8
The following figure shows a typical HDR monitoring setup for
ST2084(10K):
Tile 1: Waveform display with HDR graticule.
Tile 2: Waveform display with the HDR zoom mode enabled.
Tile 3: Picture display with specular highlighting enabled.
Tile 4: Video Session display.
www.tek.com/waveform-monitor/wfm-wvr5000–series
WFM5200 Series and WVR5200 Series Release Notes
