16.4

Material data

Liquid ends
Version Dosing head
NP Clear acrylic
PV PVDF
SS Stainless steel 1.4404 Stainless steel 1.4404 PTFE
Pump
Version Housing
All Polyphenyl ether
(PPE with fibreglass)
16.5

Electrical data

Version: 100 - 230 V ±10 %, 50/60 Hz
16.6

Temperatures

Pump, compl.
Liquid end, long-term*
Liquid end, short-term*
Suction/discharge
connector
PVDF
PVDF
Hood
Polyphenyl ether
(PPE with fibreglass)
Data
Power rating, approx.
Nominal current, approx.
Switch on peak current, (within approx.
50 ms falling
Fuse
Fuses must have VDE, UL and CSA approvals. e.g. Series SPT, 1.6 A
supplied by Schurter Order no. 0001.2506 according to IEC Publ. 127 -
2/3.
Data
Storage and transport temperature
Ambient temperature in operation (drive
and control):
Data
Liquid end temperature
* long term at max. operating pressure, dependent on ambient and feed
chemical temperatures
Material version Value
NP_ 60
PVT 120
SST 120
Seals Valve balls
PTFE Ceramic
PTFE Ceramic
Ceramic
Transparent cover Electronics
Polycarbonate Electronic compo‐
nents
0.90 ... 0.55 A
–10 ... +50 °C
–10 ... +45 °C
-10 ... +45 °C
Unit
°C
°C
°C
Technical data
Value Unit
73 W
8 ... 4 A
1.6 AT
Value Unit
Value Unit
87
