ProMinent delta DLTa optoDrive Operating Instructions Manual page 109

Solenoid metering pump with controlled solenoid drive
Table of Contents

Advertisement

Item.
Description
5
Valve compl. PVT
6
Diaphragm
7
Safety diaphragm
8
Diaphragm rupture reporter*
20
Ball seat disc PTFE
21
Shaped composite seal
Spring (item 2) and diaphragm rupture reporter (item 8) are accessories. The items listed are included in the spare
parts kit, excluding the diaphragm rupture reporter. Technical changes reserved.
0450
1002267
1000251
1027414
1027416
740063
1019364
Exploded view drawings
0280
1002267
1025075
1027414
1027416
740063
1019364
109
