Item. Description
1 Connector kit 12/9 PCE
Connector kit 8/5 PCE
Connector kit 12/9 PCB
Connector kit 8/5 PCB
3 4 Valve balls
5 Discharge valve compl. PCE
Discharge valve compl. PCB
6 Diaphragm
7 Safety diaphragm
8 Diaphragm rupture reporter*
9 Suction valve compl. PCE
Suction valve compl. PCB
Spring (item 2) and diaphragm rupture reporter (item 8) are accessories. The items listed are included in the spare
parts kit, excluding the diaphragm rupture reporter. Technical changes reserved.
Exploded view drawings
Type 1608/2508
817049
817048
817051
817053
404201
740349
740348
1030353
1027414
1027416
792119
792026
