ProMinent delta DLTa optoDrive Operating Instructions Manual page 103

Item. Description
1 Connector kit 12/9 PCE
Connector kit 8/5 PCE
Connector kit 12/9 PCB
Connector kit 8/5 PCB
3 4 Valve balls
5 Discharge valve compl. PCE
Discharge valve compl. PCB
6 Diaphragm
7 Safety diaphragm
8 Diaphragm rupture reporter*
9 Suction valve compl. PCE
Suction valve compl. PCB
Spring (item 2) and diaphragm rupture reporter (item 8) are accessories. The items listed are included in the spare
parts kit, excluding the diaphragm rupture reporter. Technical changes reserved.
1612 1020
817049 817049
817048 817048
817051 817051
817053 817053
404281 404281
1001439 1001439
1001438 1001438
1000248 1000249
1027414 1027414
1027416 1027416
1001435 1001435
1001434 1001434
Exploded view drawings
0730
817049
817048
817051
817053
404281
1001439
1001438
1000250
1027414
1027416
1001435
1001434
