FC 300 Profibus
About PROFIBUS DP V1
By operating the FC 300 frequency converter via a field bus you can reduce the capital cost of your system,
communicate faster and more efficiently, and enjoy an easier user interface.
Using PROFIBUS DP V1 you are additionally guaranteed a product which has wide compatibility, a high level
of availability and support, and which will be compatible with future versions. 10.
With the MCT 10 PC software tool you can control and configure your system simultaneously, and monitor
the entire system more effectively for faster diagnosis, and better preventive maintenance. Simplify
commissioning, maintenance and documentation using MCT.
Features of PROFIBUS DP V1:
Capital savings
•
PROFIBUS DP V1 permits very effective use of PLC I/O capacity, in effect expanding the volume capacity
of your existing PLC by up to two-thirds.
Fast and efficient communication
•
short bus cycle times
•
improved network efficiency
Easy to use
•
transparent installation, diagnosis and parameterisation
Flexibility and compatibility
•
Two different state machines can be selected: PROFIdrive profile or Danfoss FC profile
•
Communication using PROFIBUS DP V1, Master Class 1 and Master Class 2
Future-proof investment
•
Downward compatibility: New protocol extensions retain all the functions of the previous versions
•
Continuous development of new application-oriented profiles
•
Wide product availability
•
Intelligent base for future technologies such as OPC, FDT/DTM, PROFINET
Technical features:
•
Bus time out reaction
•
PLC/CPU stop reaction
•
Eight PPO types available
•
Numerous relevant process data (PCD) types available
•
Automatic detection of baud rate and PPO type
•
Extended diagnosis available
•
Alarms and warnings available as text messages within the PLC
•
Equidistant bus cycle time configurable in PLC system
•
Improved network efficiency, since the cyclic parameter channel is no longer required
•
Very short bus cycle times compared to industrial ethernet
•
Backwards compatibility with DP
8
Introduction
MG.33.C2.02 - VLT is a registered Danfoss trademark
