FC 300 Profibus
- Disable: Disables process control via Profibus, and
enables process control via standard RS485.
- Enable cyclic master: Enables process control
via Profibus Master Class 1, and disables process
control via standard RS485 bus or Master class 2.
9-53 Profibus Warning Word
Option:
Bit: Meaning:
0 Connection with DP-master is not
1 Timeout action active
2 FDL (Field-bus Data link Layer) is not ok
3 Clear data command received
4 Actual value is not updated
5 Baudrate search
6 PROFIBUS ASIC is not transmitting
7 Initializing of PROFIBUS is not ok
8 Drive is tripped
9 Internal CAN error
10 Wrong ID sent by PLC
11 Internal error occured
12 Not configured
13 Clear command received
14 Warning 34 active
Function:
Displays Profibus communication warnings.
9-63 Actual Baud Rate
Option:
Read only
9.6 kbit/s
19.2 kbit/s
93.75 kbit/s
187.5 kbit/s
500 kbit/s
1500 kbit/s
3000 kbit/s
6000 kbit/s
12000 kbit/s
31.25 kbit/s
45.45 kbit/s
No baudrate found
Function:
Displays the actual PROFIBUS baud rate. The
Profibus Master automatically sets the baud rate.
9-64 Device Identification
Array [10]
Option:
Read only
Array
Parameters
The device identification parameter. The data type
is "Array[n] of Unsigned16". The assignment of the
first subindexes is defined and shown in the table
above.
Contains the profile identification. Byte 1 contains
the profile number and byte 2 the version number
of the profile.
[1]
[0]
[1]
[2]
[3]
[4]
[6]
[7]
[8]
Accepts the Control word from a Master Class 2 in
[9]
the same format as PCD 1. If control priority is set
[10]
to Master Class 2, the Control word for the drive
[11]
is taken from this parameter, whereas cyclical and
[255]
acyclic reference from a Master Class 2 is ignored.
This parameter is only visible for Profibus Master
Class 2, not for Master Class 1, standard bus or LCP.
[255]
[10]
