5.3.4

Expert menu (TIG)

The Expert menu has adjustable parameters stored that don't require regular setting. The number of
parameters shown may be limited, e.g. if a function is deactivated.
Display
099-007027-EW501
28.08.2018
ENTER
Setting/selection
Expert menu
Slope time (main current to secondary current)
Slope time (main current to secondary current)
Slope time (secondary current to main current)
Slope time (main current to secondary current)
Ignition type (TIG)
------- HF start active (ex works)
------- Lift arc ignition active
Design and function
Figure 5-22
TIG welding
EXIT
