Levelflex FMP56, FMP57
Endress+Hauser
Housing GT18 - stainless steel, corrosion-resistant
No. Part: material
2.2 Terminal compartment
• Cover: 316L (CF-3M)
• Cover seal: EPDM
3 Cover lock
• Screw: A4
• Clamp: 316L (1.4404)
4 Turn housing
• Screw: A4-70
• Clamp: 316L (1.4404)
No. Part: material
1 Housing: PBT
2.1 Compartment for the display module
• Cover: PBT / PA
• Cover seal: EPDM
2.2 Terminal compartment
• Cover: PBT
• Cover seal: EPDM
4 Turn housing
• Screw: A4-70
• Clamp: 316L (1.4404)
Housing GT20 - die-cast aluminum, powder-coated, seawater-resistant
No. Part: material
1 Housing: AlSi10Mg(<0.1% Cu)
2.1 Compartment for the display module
• Cover: AlSi10Mg(<0.1% Cu)
• Window: glass
• Cover seal: EPDM
2.2 Terminal compartment
• Cover: AlSi10Mg(<0.1% Cu)
• Cover seal: EPDM
3 Cover lock
• Screw: A4
• Clamp: 316L (1.4404)
4 Turn housing
• Screw: A4-70
• Clamp: 316L (1.4404)
Further material specifications
• Materials in contact with process (® ä 31)
• Ordering information (® ä 44)
• Accessories materials (® ä 48)
No. Part: material
6 Dummy plug: 316L (1.4404)
7 Pressure relief stopper: 316L (1.4404)
8 Ground terminal
• Screw: A4
• Spring washer: A4
• Clamp: 316L (1.4404)
• Holder: 316L (1.4404)
9 Identification
• Nameplate: 304 (1.4301)
• Groove pin: A2
Housing GT19 - plastic
No. Part: material
5 Cable entry
• Sealing: EMPB
• Cable gland: polyamide (PA), nickel-plated brass (CuZn)
• Adapter: 316L (1.4435)
6 Dummy plug: PBT
7 Pressure relief stopper: PBT
8 Ground terminal
• Screw: A2
• Spring washer: A4
• Clamp: 304 (1.4301)
• Holder: 304 (1.4301)
9 Identification
Nameplate: sticker
No. Part: material
5 Cable entry
• Sealing: EMPB
• Cable gland: polyamide (PA), nickel-plated brass (CuZn)
• Adapter: 316L (1.4435)
6 Dummy plug: nickel-plated brass (CuZn)
7 Pressure relief stopper: nickel-plated brass (CuZn)
8 Ground terminal
• Screw: A2
• Spring washer: A2
• Clamp: 304 (1.4301)
• Holder: 304 (1.4301)
9 Identification
Nameplate: sticker
37
