Levelflex FMP56, FMP57
B
ø59.5
(ø2.34)
SW55
AF55
SW14
AF14
E
SW14
AF14
ø16
(ø0.63)
mm (in)
Endress+Hauser
FMP57: Dimensions of process connection and probe
C
ø59.5
(ø2.34)
SW55
AF55
SW14
AF14
F
SW14
AF14
ø6
(ø0.24)
M20
ø30
(ø1.18) (ø1.18)
A Mounting bracket for probe design "Sensor remote" (Feature 600)
B Thread ISO228 G1-1/2 (Feature 100)
C Thread ANSI MNPT1-1/2 (Feature 100)
D Flange ANSI B16.5, EN1092-1, JIS B2220 (Feature 100)
E Rod probe 16mm (Feature 060)
F Rope probe 6mm or 1/4" (Feature 060)
G Rope probe 8mm or 1/3", PA>Steel (Feature 060)
H Rope probe 4mm or 1/6" (Feature 060)
I Rope probe 6mm or 1/4", PA>Steel (Feature 060)
LN Length of probe
R Reference point of the measurement
D
ø59.5
(ø2.34)
SW14
AF14
G
SW14
AF14
ø8
(ø0.31)
M20
ø30
(ø0.87)
122
(4.8)
ø82.5
(ø3.25)
R
H
SW14 SW14
AF14 AF14
ø4
(ø0.16)
M14
ø22
ø22
(ø0.87)
A
I
ø6
(ø0.24)
M14
A0012782
35
