Tolerance Of Probe Length; Weight; Material - Endress+Hauser Levelflex FMP56 Manual

Tolerance of probe length

Weight

Material

36
Over [m (ft)]
Up to [m (ft)]
Admissible tolerance [mm (in)]
Over [m (ft)]
Up to [m (ft)]
Admissible tolerance [mm (in)]
Housing
Part
Housing GT18 - stainless steel
Housing GT19 - plastic
Housing GT20 - aluminium
FMP56
Part Weight
Sensor approx. 0.8 kg
FMP57
Part Weight
Sensor approx. 1.4 kg + weight of flange
Rope probe 4 mm approx. 0.1 kg/m probe length
2.1
4
Housing GT18 - stainless steel, corrosion-resistant
No. Part: material
1 Housing: 316L (CF-3M)
2.1 Compartment for the display module
• Cover: 316L (CF-3M)
• Window: glass
• Cover seal: EPDM
Rod probes
— 1 (3,3)
1 (3,3) 3 (9,8)
-5 (-0,2) -10 (-0,39)
Rope probes
— 1 (3,3)
1 (3,3) 3 (9,8)
-10 (-0,39) -20 (-0,79)
Weight
approx. 4.5 kg
approx. 1.2 kg
approx. 1.9 kg
Part
Rope probe 4 mm
Rope probe 6 mm
Part
Rope probe 6 mm
Rod probe 16 mm
1 2.2
3 9
No. Part: material
5 Cable entry
• Sealing: EMPB
• Cable gland: polyamide (PA), nickel-plated brass (CuZn)
• Adapter: 316L (1.4435)
Levelflex FMP56, FMP57
3 (9,8) 6 (20)
6 (20) —
-20 (-0,79) -30 (-1,18)
3 (9,8) 6 (20)
6 (20) —
-30 (-1,18) -40 (-1,57)
Weight
approx. 0.1 kg/m probe length
approx. 0.2 kg/m probe length
Weight
approx. 0.2 kg/m probe length
approx. 1.6 kg/m probe length
5
8 7 6
Endress+Hauser
A0013788
