A/D conversion rate (meas/s)
50-Hz rejection
6,25
12,5
25
50
100
200
400
800
1600

14.2.7 Decimal point position

Although eNod4 measurements are integer values it is however possible to store a 'decimal point position' so as to
design a display related to the application. Its value represents the number of decimal digits. If the variable is set to
Zero, it means that decimal point is not used.
Decimal point position has a consistency and influences flow rate values.
Note: the decimal point is directly integrated to SCMBus protocol frames (see § SCMBus).
Admitted values: from 0 up to 7.

14.2.8 Weight unit

It is possible to store the display weight unit into the eNod4.
This weight unit is a combination of 4 characters and data has no consistency. There is no automatic calculation to
adjust flowrate values neither flowrate calibration values.
Note: the unit is directly integrated to SCMBus protocol frames (see § SCMBus).

14.2.9 Flow rate time unit

It is possible to store the display flow rate time unit into the eNod4.
Flow rate time unit is a combination of 2 characters and there is no automatic calculation to adjust flow rate value if
modified.
In loss in weight feeder mode, following values are permitted for flow rate time unit parameter:
•
0x2073 for seconds (s)
•
0x6D6E for minutes(mn)
•
0x2068 for hours (h)
In opposition to the weight unit behaviour, the flowrate unit is consistent for instant and average flowrate
determination. However and when the time unit is modified, there is no automatic redetermination of calibration
flowrate values.

14.2.10 Save Tare and Zero in non-volatile memory

There are two options for saving TARE or ZERO request value in non-volatile memory. These options are accessible
through the "dosing cycle options" Object.
60-Hz rejection
7,5
15
30
60
120
240
480
960
1920
76/113
User manual SCAIME:
NU-Soft-eNod4F-ETH-E-0716_235709-C.doc
X
1
2
3
5
9
17
33
65
129
