13.2.9 Set points high and low values

Each set point is described by its commutation mode (hysteresis/window) and by a couple of values that are
constantly compared to the gross or net measurement or to dosing result or dosing running total (depending on the
configuration the set point has been given) in order to define the corresponding output logical level. For more details
about the set points functioning, please refer to documentation eNod4 "characteristics and functioning".
Admitted values: from -1000000 to 1000000.
meaning
gross
net
Sensor input control result
72/113
User manual SCAIME:
NU-Soft-eNod4F-ETH-E-0716_235709-C.doc
set point 4 comparison measurement
reserved (0)
note
