Scaime eNod4-F ETHERNET Software User Manual page 93

Chapter Name
Calibration of flow
rate point 1
Dosing
(control output
value)
Calibration of flow
rate point 2
Dosing
(control output
value)
Calibration of flow
rate point 3
Dosing
(control output
value)
Calibration of flow
rate point 4
Dosing
(control output
value)
Calibration of flow
rate point 5
Dosing
(control output
value)
Calibration of flow
rate point 6
Dosing
(control output
value)
Calibration of flow
rate point 7
Dosing
(control output
value)
Calibration of flow
rate point 8
Dosing
(control output
value)
Calibration of flow
rate point 9
Dosing
(control output
value)
Calibration of flow
rate point 10
Dosing
(control output
value)
Calibration of flow
Dosing rate point 1
(flow rate value)
EtherNet/IP
Modbus
Class/
RTU / TCP
Attribute
address
(hex/dec)
0x0A00 0x69/32
0x0A01 0x69/33
0x0A02 0x69/34
0x0A03 0x69/35
0x0A04 0x69/36
0x0A05 0x69/37
0x0A06 0x69/38
0x0A07 0x69/39
0x0A08 0x69/40
0x0A09 0x69/41
0x0A0A 0x69/42
93/113
User manual SCAIME:
NU-Soft-eNod4F-ETH-E-0716_235709-C.doc
Profinet Profinet cyclic
Record Index Req Code
R: 0x02B4
0x008F
W: 0x02B5
R: 0x02B6
0x0090
W: 0x02B7
R: 0x02B8
0x0091
W: 0x02B9
R: 0x02BA
0x0092
W: 0x02BB
R: 0x02BC
0x0093
W: 0x02BD
R: 0x02BE
0x0094
W: 0x02BF
R: 0x02C0
0x0095
W: 0x02C1
R: 0x02C2
0x0096
W: 0x02C3
R: 0x02C6
0x0097
W: 0x02C7
R: 0x02C8
0x0098
W: 0x02C9
R: 0x04CA
0x0099
W: 0x04CB
EtherCAT
index/sub- Type Access
index
0x470A / 0x01 Uint RW
0x470A / 0x02 Uint RW
0x470A / 0x03 Uint RW
0x470A / 0x04 Uint RW
0x470A / 0x05 Uint RW
0x470A / 0x06 Uint RW
0x470A / 0x07 Uint RW
0x470A / 0x08 Uint RW
0x470A / 0x09 Uint RW
0x470A /
Uint RW
0x0A
0x470B / 0x01 float RW
