eNod4-B ETHERNET
Digital Process Transmitter
NU-eNod4B-ETH-E-236708-D.docx
SCAIME SAS – Technosite Altéa – 294, Rue Georges Charpak – 74100 JUVIGNY - FRANCE
Tél. : +33 (0)4 50 87 78 64 – www.scaime.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the eNod4-B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Scaime eNod4-B

Summary of Contents for Scaime eNod4-B

  • Page 1 ETHERNET Digital Process Transmitter NU-eNod4B-ETH-E-236708-D.docx SCAIME SAS – Technosite Altéa – 294, Rue Georges Charpak – 74100 JUVIGNY - FRANCE Tél. : +33 (0)4 50 87 78 64 – www.scaime.com...

  • Page 2: Table Of Contents

    6 CALIBRATION AND SCALE ADJUSTMENT ............. 26 6.1 Physical calibration ..................26 6.2 Theoretical calibration ................. 26 6.3 Scale adjustment coefficient ..............26 6.4 Gravity correction ..................26 6.5 Scale interval ....................26 7 FILTERS ........................27 SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...
  • Page 3 11.2.4 Minimum load to totalize (weight unit/meter) ........37 11.2.5 Pulses factor speed sensor (Pulses/meter) ........37 11.2.6 Measurement time factor for speed (x250ms) ......... 37 11.2.7 Constant belt speed (m/s) ..............37 11.2.8 Flow correction factor ................. 37 SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...
  • Page 4 12.1.1 Startup screens ..................42 12.1.2 Multi-eNod screens ................43 12.1.3 Main screen ..................47 12.1.4 Main setup menu ................50 12.2 Belt parameter configuration (eNod4-B) ..........70 12.2.1 Flow Rate ....................71 12.2.2 Dosing Alarms ..................72 12.2.3 Conveyor ..................... 74 12.2.4 Speed ....................

  • Page 5: Safety Instructions

    Warning: situation potentially dangerous that could lead to death. CAUTIOUS Cautious: situation potentially dangerous that could lead to injuries. 1.1 Getting started WARNING Security provided by this product is provided for use for its intended purpose. Maintenance can only be performed by qualified staff. SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 6: Protection

    2. Disconnect the power cords from the outlets. 3. Connect the interface cables to the connectors. 3. Disconnect the interface cables from the connectors. 4. Connect the power cords into outlet. 4. Disconnect all cabled from the units. 5. Turn on the units. SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 7: Enod4 Product Range

    In conjunction with all communication protocol versions and IO+ version, eNod4 can supports a communication board that allows to exchange information via Bluetooth®. Radio information Wireless communication Bluetooth® Low Energy 4.2 Max. RF output power -16.9 dBm Frequency range 2.4 – 2.4835 GHz SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 8: Enodview Software

    2.3 eNodView Software So as to configure eNod4, SCAIME provides eNodView software tool. eNodView is the software dedicated to eNod devices and digital load cell configuration from a PC. This simple graphical interface allows accessing the whole functionalities of eNod4 for a complete setting according to the application.

  • Page 9: General Characteristics

    3 GENERAL CHARACTERISTICS 3.1 Dimensions SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...
  • Page 10 SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 11: Electrical Characteristics

    Metrological specifications on A3 connector input (load-cell type sensor)  7.8 Input sensor range for a load cell sensor mV/V Thermal zero drift typical ppm/°C Thermal span drift typical ppm/°C Linearity deviation 0.003 % FS Conversion rate 6.25 ... 1920 meas./s SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 12: Legal For Trade

    Maximum voltage of the weighing range Value of factor p Minimum impedance for the load cell Type of load cell(s) connection system 4-wire or 6-wire Maximum impedance for the load cell 1500 Maximal length/section measurement cable m/mm SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...
  • Page 13 The minimum time between two DSD recording operations is 50ms. * legal for trade use does not apply to software applicative for beltweigher (-B) and weigh feeder (-F) SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 14: Connections

    6-wire / 4-wire loadcell wiring power supply Exc+ Résistance de terminaison connexion AUX AUX connection termination resistor Sens+ Exc- RB/TB (B-) connexion capteur Sens- RA/TA (A+) connexion AUX load cell AUX connection Sig+ connection Sig- Shield IN5-HTL SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 15: Cabling Basic Rules

    For ESD protection, cabling for the analog load cell must include a ferrite and a silicone protection sleeve, not included with the transmitter. Install the ferrite by passing the analog cell connection through the ferrite and wrapping it around once, as shown on the following picture: SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 16: Prevent Electromagnetic Disturbances

    Create a homogeneous reference potential and ground all electrical equipment. Use sufficiently dimensioned equipotential bonding conductors if potential differences exist or are expected between your system components. Equipotential bonding is absolutely mandatory for applications in hazardous areas. SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 17: Power Supply Connection

    3.6mA. It is software setting and both output (current and voltage) might separately be enable. Current output connection Voltage output connection Iout Iout GNDA GNDA Vout Vout The IO+ version is fitted with two additional inputs IN3 and IN4: SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 18: Inputs / Outputs Connections

    Speed sensor input connection IN5-TTL IN5-TTL V supply IN5-HTL IN5-HTL GNDA GNDA IN4+ IN4+ IN3+ IN3+ Iout Iout GNDA GNDA Vout Vout 4.5 Inputs / outputs connections An indicator light in front panel is assigned to each Output. SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 19: Typical Connections

    4.5.1 Typical connections Inputs : Connection to a detector Inputs : Connection to a push button Outputs : Possible connections Load Load Load 4.6 JB4 option SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 20: Specifications

    Load successively each corner with the same reference weight and adjust at each step the potentiometer to match the lowest output corner value. 4. The load cells outputs are now matched. Then proceed to normal zero and gain adjustment of the weighing indicator. SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 21: Spring Terminal Connections

    2. Stick the wire end into the relevant opening. 3. Release the pressure on the screwdriver. 4. Pull slightly the cable to check it is held tight. 7-10mm 4.7 220V option Plug the supplied power cord into the AC outlet. SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 22: Communication

    USB Communication stops AUX communication when used. The appropriate USB driver can be downloaded from our website: www.scaime.com. It is also available on CD to order from our sales department. Note: If eNodView software has been correctly installed, it is not mandatory to re-install the USB drivers when connecting another eNod4 on the same USB port (Windows only asks for the driver if the device is connected to another USB port).

  • Page 23: Communication Rate Selection

    EtherNet/IP eNod4 Ethernet NS état du réseau EtherCAT NS Network Status MS défaut système (vert) Ethernet / défaut bus (rouge) MS system failure (green) Profinet / bus failure (red) NS état du réseau NS Network Status SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 24: Simultaneous Functioning Of Communications

    PC Connection Simultaneous Ethernet RS485 AUX communication yes* Ethernet Yes** (*) Simultaneous use of Ethernet with USB port can reduce performance of this interface. (**) In this configuration, we recommend low speed rate on AUX output. SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 25: Bluetooth ® Communication (Optional)

    Set application parameters, And more… The theoretical range of the Bluetooth® communication is about 10 meters without obstacles. eNodApp application is available in English and French version and can be downloaded from the Google Play Store. SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 26: Calibration And Scale Adjustment

    6.5 Scale interval The scale interval is the difference between 2 consecutives indications. Possible values are: 1, 2, 5, 10, 20, 50, and 100. Modification of scale interval is taking into account after a new calibration. SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 27: Filters

    This filter can be set in cascade after the previous filters. The Moving average filter is used to smooth the weight value in case of random interferences. This sliding average computes the mean of the ‘n’ last measures from the results of the previous activated filters. A high filter depth gives a better stability, with a longer response time. SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 28: Measurement And Status

    The second, when the user wants to check the integrity of the system, allows to make the difference between a new simulated weight value and the reference. Then this difference can be compared with a dedicated maximum tolerance value. SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 29: Inputs Functioning

    Depending on the chosen logic (positive or negative), the zero is triggered by a rising or a falling edge. 9.2.5 Transmit measurement This is only possible using standard or fast SCMBus format or CANopen® protocols. The request can apply to:  gross measurement. SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 30: Measurement Window

    (e.g. after the device is calibrated). Note: Load cell sensor input control must be realized if no process cycle is in progress. 9.3 Functions attached to an operating mode: See corresponding sections for a complete description. SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 31: Outputs Functioning

    3 to set point 3 and output 4 to set point 4. Set points are characterized by a high and a low value. Their operating mode is either operating in hysteresis or operating in window. SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 32: Motion

    Voltage output might be set either 0-5V or 0-10V, and the current output to 4-20mA, 0-24mA, 0-20mA or 4-20mA with alarm at 3.6mA. Both output (current and voltage) might separately be enable. Settings are effective after eNod4 reset. Analog output affectation function is common to both current and voltage output and might be assigned to followings: SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...
  • Page 33 When analog output is assigned to “Gross measurement”, “Net measurement”, “Instant flow rate” or “Average flow rate” its value jumps to a special error value when the internal alarm flag described in “Weighing diagnosis” § in the MEASUREMENT AND STATUS § is activated. This allows to warn about defection of the measurement chain. SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 34: Belt Weigher Operating Mode

    Belt scale operation In belt scale operating mode, eNod4 continuously calculates the total amount of material that goes through the weighing system and calculates the flow rate of material instantaneously. SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 35: Totalization Cycle Description

    1000 and the complementary weight to totalize in weight unit are reset to zero.  PID Activation It is possible to assign eNod4 current or voltage analog output to extraction command (Setting to flow rate control output). SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 36: Weight Section Length (Mm)

    “Belt tilt angle” (angle of conveyor in degrees) allows correcting the effect of inclination on the weight. If the belt is mounted horizontally, the definition is 0. The belt can be tilted to a maximum of 35°. Always ensure that the definition corresponds with the current tilt angle, otherwise the belt load is incorrectly calculated. SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 37: Minimum Load To Totalize (Weight Unit/Meter)

    Speed calibration must be performed when the conveyor is running and empty. The following parameters are involved during speed calibration procedure:  Pulses factor speed sensor (Pulses/meter), user can get this data from speed sensor datasheet. Using this parameter, eNod4 allows estimating the conveyor total length. SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 38: Static Weight Calibration

    If one of these 4 outputs is allocated to an external totalizer, a pulse is sent when the value totalized increases by a multiple value of the parameter weight quantity per pulse on logical output. SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 39: Alarms

    Maximum control output is the limit value for control output in 0.1% at nominal flowrate. The entry of the number e.g. 1020 corresponds to 102.0%. When the control output on the belt is higher than this level, eNod4 sets the alarms bit “>max. control output” in belt alarms register. SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 40: Minimum Belt Speed Limit Value (0.1%)

    5 Inputs (with IO+ option). One of them is especially reserved for speed sensor input. All others logical inputs can be assigned to functional dosing process commands. All process commands have edge functioning. SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 41: Start / Stop Dosing (And Batch)

    The procedure will complete its cycles unless an exit calibration command is sent.  Belt Fault Belt Fault function should be assigned to logical input. At this input activation on rising or falling edge (according to the configured logic), Belt fault alarm is activated. SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 42: Enodtouch - Human Machine Interface (Option)

    In this case, check the wiring between eNodTouch and eNod4 (§ Electrical Powering) and check that the communication parameters of eNodTouch and eNod4 are correct (§Peripheral – Device PLC Settings). Communication error screen Connection screen Redirection screen SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 43: Multi-Enod Screens

    - Go to the Starting Parameters screen by touching the right arrow button. Main Menu eNodTouch menu Starting parameters  By default the eNod number is 1, eNodTouch starts on the main screen of the first eNod. SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...
  • Page 44 According to the number of eNod settled, eNodTouch redirects to the following multi-eNod screens: Channel name Weight value Gross/Net Indicator Unit Multi eNod (2 eNod) Multi eNod (3 eNod) Multi eNod (4 eNod) Multi eNod (5 eNod) SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...
  • Page 45 Main screen of eNod  To display the main screen of an eNod, touch its display area (Example for eNod n°1):  To return to multi eNod screen, touch the channel red button: Touch of channel display Multi-eNod screen SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...
  • Page 46 The display module tries to recover the communication with eNod4 during 1 second, the button toggles to the « Reconnection » state. After 1 second if data from the eNod4 appears, the communication is re-established, else the button toggles to « eNod disconnected » state. SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 47: Main Screen

    12.1.3 Main screen 12.1.3.1 Dosing Mode (eNod4-B) Totalization Control output Total per belt value revolution Average flow rate Nominal flow rate Weigh frame load Dosing weight Dosing cycle deviation status Belt speed status Second Keyboard  To switch from the main keyboard to the 2 keyboard touch ...
  • Page 48 D, F and B. Quick access can be configured to manage what is accessible in this menu for eNod4-D and F. Weighing result acquisition (DSD) only in transmitter functioning mode. SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...
  • Page 49 The Diagnostic screen can be called using the key Logical inputs Logical output Display of the High- Resolution net weight (on legal for trade Net weight certified version) Run the sensor input control command Sensor input control result SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 50: Main Setup Menu

    Setup menu access can be secured by password (see § 3.5.1). In that case, the following screen is displayed:  After entering a valid password (or OLEG if you’ve forgot your password), the following menu will be displayed: eNod4-D : Dosing Modes eNod4-F : Dosing Modes eNod4-T : Transmitter Mode eNod4-C : Checkweigher Mode SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...
  • Page 51 Dosing modes 12.1.4.1 eNodTouch setup Parameter Possible Value Description Language [Fr], [En] Change the language of eNodTouch software Keyboard mask [Yes], [No] Enable/Disable keyboard display on main screen [Yes], [No] Enable/Disable access protection to setup menu Password 4 Char By default, “OLEG”...
  • Page 52 If there is only one eNod4 supported this function is necessarily activate. 12.1.4.3 Calibration Menu When using eNod4 for legal for trade purpose, it is imperatively required to activate the legal for trade switch BEFORE any calibration procedure (cf § legal for trade switch). SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...
  • Page 53 Weight measurement unit (g, kg, t, lb…) using for calibration Time unit using for calibration (eNod4-F and B). Only s and h can be Time unit s, mn, h selected in eNod4-B. Weight unit (display g, kg, t Weight unit of flow rate which is displayed on main screen.
  • Page 54 Allows creating relation between the weighing sensor and the physical values. Number of loads 1, 2, 3 Number of calibration loads used during the physical calibration. Load 1/2/3 1 – 1 000 000 Weight values corresponding to each calibration segment. SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...
  • Page 55 1. Emptying the scale and press 2. Wait for the end of data acquisition. Remark : If you press the operation will stop and the values will not be saved. The latest valid calibration values will be restored. SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...
  • Page 56 Remark : If you press the operation will stop and the values will not be saved. The latest valid calibration values will be restored. Theoretical calibration An automatic scaling to migrate from the factory calibration to the user calibration. SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...
  • Page 57 Load cell sensitivity in mV/V at maximum capacity Span Calibration correction Span. cor 0.9 – 1.100000 Allows to adjust initial calibration Calibration g >0 (9.805470) Allows compensating the gravity difference between calibration place and using place. Use g >0 (9.805470) SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...
  • Page 58 12.1.4.4 I/O setup (IO+ version only) (Available depending on version) SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...
  • Page 59 Dynamic Zero, Manual emptying, Belt fault Logic [Positive]-[Negative] defines the edge (or level) that triggers input function Debounced time 0 – 6553 ms Minimum required time of the logical inputs before their activation Output 1-4 Parameters eNod4-F external totalizer (Page 2) SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...
  • Page 60 When an overflow is occurred on pulses output an alarm is set. Thresholds control Allows modifying the Threshold values of the concerned outputs. Remote Control Allows fixing the level [On], [Off], of the concerned outputs. SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...
  • Page 61 In Checkweigher, allows modifying timings on outputs with functions « Remote control » (activation time), « Result within tolerances » and « Result out of tolerances » (activation time and delay). Parameters Analog output (IO+ version only) Analog output remote (Page 2) with “remote control” function or “Flow Rate Ctrl” function SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...
  • Page 62 “defective 0 – 65535 ms alarm activation measurement alarm activation time” when it come to be active and time whatever the error conditions are during activation. 12.1.4.5 Configuration setup SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...
  • Page 63 Parameter Possible Value Description Metrology Parameters SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...
  • Page 64 Save Tare in FRAM [Yes], [No] It allows saving tare in non-volatile memory (FRAM). Save Zero in FRAM [Yes], [No] It allows saving zero in non-volatile memory (FRAM). Audit trail (Available depending on version) SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...
  • Page 65 Data Storage Device (Available depending on version) Record ID to read Record of the ID to be read. Erase all records from the DSD memory. This is possible only when the legal for trade sealing is disabled. SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...
  • Page 66 Option « Use rotary Allows on Save automatic appending of hexadecimal representation of rotary switches in the switch in Name » Name. Byte order Byte order in Profinet exchanges ([Little Endian], [Big Endian]) SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...
  • Page 67 0.10 Hz for 6.25 meas/s, 4 Hz for 400 meas/s  Notch Filter parameters High & Low 0.1 to 200Hz Frequency band to attenuate with the digital Notch filter Frequency * * May not be implemented depending on eNod4 applicative version. SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...
  • Page 68 Allows resetting eNod4 or making eNod4 come back to factory settings Channel name Name or rename the channel with a maximum of 4 characters Parameter Possible Value Description Sensor Input Control Parameters (Available depending on version) SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...
  • Page 69 This command must be performed before using the Sensor input control command and each time the weight measurement chain (sensor, connection, calibration) is modified. This command must not be realized when any process cycle that use weight is in progress. SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 70: Belt Parameter Configuration (Enod4-B)

    12.2 Belt parameter configuration (eNod4-B)  Detailed explanations on Dosing functioning and parameters could be found into eNod4-B manuals  The following setup menu allows modifying the parameters related to Belt setup. SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 71: Flow Rate

    Weight / pulse external totalizer 0 – 65535 parameter. When an overflow is occurred on pulses output an alarm is set.  To access the correction touch SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 72: Dosing Alarms

    The next batch the Batch Total and Checked Batch Total should be closer together. Important: Before initiated this command, user has to configure the “Real Batch” parameter. 12.2.2 Dosing Alarms Parameter Possible Value Description Dosing Alarms Parameters SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...
  • Page 73 Inhibit time belt fault 0 – 65535 sec Inhibition time in service of belt fault monitoring in second. alarm in service Stop/Susp. dosing on Yes / No Stop totalization function if alarm occurred alarms default SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 74: Conveyor

    0 – 3500 sec alarm duration belt start. The buzzer duration depends on this parameter value in second. Number of Specifies the real belt revolutions to realize during speed/length 1 - 65535 Revolutions calibrations and dynamic zero procedure. SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 75: Speed

    Defines the belt speed in m/s if no speed sensor is connected to eNod4. Maximum pulses per 0 - 65535 Defines constant maximum pulses number of speed sensor. meter Speed determination 1 – 65535 Specifies the belt speed determination time in multiple of 250ms. time factor (250ms) SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 76: Batch Dosing

    Weight target 0 – 9999999.9 The batch target in weight unit -9999999.9 – Totalization inflight The batch target inflight value in weight unit. 9999999.9 SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 77: Pid

    PID parameters auto- adjustment command will cause eNod4 to perform successive dosing cycle (10) sequences to calculate optimized PID coefficients Kp, Ti and Td. SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...

  • Page 78: Flow Rate Calibration

    (Visualization of the flow rate on the main screen or through eNodView application), 5. Press to validate this calibration (save in volatile memory). 6. Press to store in non-volatile memory the values entered. Note : the arrows, allow navigation between screens and back to the previous menu. SCAIME Manual : NU-eNod4B-ETH-E-236708-D.docx...
