Max permissible flow rate control output: high limit of flow rate output control output value over which a
flow rate control output occurs, cf § flow rate / control output alarms. Expressed in 0.1% of nominal flow
rate.
•
Inhibit time of flow rates alarms at start: time throughout no flow rate alarm or flowrate control alarm will
occur when a cycle is starting to allow dosing stabilization, cf § flow rate / control output alarms. Expressed
in seconds.
•
Inhibit time of flow rates alarms in service: time throughout flow rate or flow rate control output values
should be kept outside the limit specified for an alarm to occur and after the Inhibit time of flow rates
alarms at start, cf § flow rate / control output alarms. Expressed in seconds.
•
Maximum time for refilling start: maximal delay to the gross weight to be higher than its value at refilling
start. The aim is to detect no material fall when activating the refilling whether it is a manual or automatic
control (lack of material, clogging, valve or control failure), cf § refilling alarms. Expressed in seconds.
•
Time interval for weight variation control on refilling: time during which a weight variation should be
positive. The aim is to detect any malfunction during the refilling phase (lack of material or clogging), cf §
refilling alarms. Expressed in seconds.
•
Maximum refilling time: maximal time for the refilling phase to complete, cf § refilling alarms. Expressed in
seconds.
•
Totalizer value (Great WU)): the main totalization result in weight unit x 1000, cf § totalization.
•
Complementary totalizer value: the complementary totalization result in weight unit., cf § totalization.
•
Dosing status: this register describes dosing cycle phases and additional information on the feeder
functioning. See following table:
bits set to 1
b ... b
7 0
b Stop
0
b Refilling
1
b Learning cycle end of refill delay
2
b End of refilling stabilization
3
b Flow rate determination
4
b Dosing
5
b Batch suspended
6
b Hopper emptying
7
b
8
b ... b
15 9
b Learning cycle
9
b Flow rate calibrated
10
b Volumetric dosing
11
b Extraction activated
12
b Refilling in progress
13
b Dosing cycle in progress
14
b Batch complete
15
•
Dosing errors report: this register describes exclusively the status of alarms that can occur, cf § alarms.
See coding definition in the table below:
User manual SCAIME:
Meaning
Dosing steps
Reserved (0)
Additional informations
