9.1.4 Factory calibrated points

The 'factory calibrated points" contains the measurement value without the user calibration layer. It is directly linked
to the analog input voltage.

9.1.5 Preset Tare value

A previous calculated tare can be restored using this variable.

9.1.6 Measurement status

The measurement status contains information on eNod4 measurement parameters.
The 'measurement status' bytes contain information about every measurement processed by eNod4. See the flags
meaning in the table below:
bits
b b
1 0
00
01
10
11
b b
3 2
00
01
10
11
b
4
0
1
b
5
0
1
b
6
0
1
b
7
0
1
Meaning
gross measurement
net measurement
factory calibrated measurement
tare value
measurement OK
Defect: sensor input control result out of
tolerances OR Sensor input control
command in progress OR failed (timeout)
OR Sensor input reference command in
progress
gross meas.< (- max capacity) OR gross
meas. > (max capacity)
analog signal out of the A/D converter input
range
motion
no motion
measurement out of the ¼ of division
zero in the ¼ of division
EEPROM OK
EEPROM failure
reserved
43/113
User manual SCAIME:
NU-Soft-eNod4F-ETH-E-0716_235709-C.doc
Note
only in SCMBus/fast communication
protocols
not significant otherwise (00)
causes a logical output assigned to the
'defective measurement' function to be
set active. Causes the analog output
assigned to a weight or flow rate
image to be set in error mode.
causes an output assigned to the
'motion' function to be set active
See Note 1
1 in SCMBus and fast SCMBus, 0
otherwise
