Scaime eNod4-F ETHERNET Software User Manual page 21

Register address Size in
(Hex) bytes (n)
007D 2
007E 4
0080 4
0082 4
0084 4
0086 4
0088 4
008A 4
008C 2
008D 4
008F 2
0090 2
0091 2
0092 4
0094 2
0095 4
0097 4
0099 2
009A 2
009B 2
009C 2
009D 2
009E 4
00A0 4
00A2 4
00A4 4
00A6 4
00A8 4
*for possible check of the performances
Type Name
Uint measurement status
long gross measurement
long tare value
long net measurement
long factory calibrated points
Float instant flow rate
Float average flow rate
Float Flow rate control output
Uint Control output value
Ulong Totalizer value (Great WU)
Uint Complementary totalizer value
Uint command register
Uint response register
long Zero offset
Uint Logical I/O level
Float Dosing weight deviation
long Preset tare
Réservé
Uint Dosing status
Uint Dosing errors report
Uint Dosing errors counter
Uint Last dosing error
Float Dosing quality factor
Float Totalization flow rate
Ulong Grand total (Great WU)
Ulong General total (Great WU)
Float Extraction time
Ulong eNod4 1ms counter*
21/113
User manual SCAIME:
NU-Soft-eNod4F-ETH-E-0716_235709-C.doc
Access
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
R/W
RO
R/W
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
